Refrigeration units
The refrigerator's refrigeration unit is the appliance's cooling system, which transfers heat from the inside of the cabinet to the outside. It is responsible for circulating the refrigerant, which maintains the optimal temperature.Refrigeration units -ryhmän tuotteet
Uniqool cooling unit UCS35 Slim + EV20 for insulated spaces up to 130 liters – reliable performance, easy installation and a complete solution with digital control.
This cooler is designed to provide efficient and reliable cooling in insulated spaces up to 130 liters. The complete "all-in-one" solution includes all the necessary components in one package, making installation quick and easy, even in tight spaces.
The package combines the proven cooling performance of the BD35 and BD50F models with the EV20 GR evaporator in a convenient Plug & Play solution with digital control, making it ideal for use in boats and RVs where energy efficiency and reliability are crucial.
- Condensing unit: UCS35 Slim GR
- Evaporator unit: EV20 GR
- Thermostat: Digital Uniqool
- Power supply: 12/24V
- Maximum cooling capacity: 130 liters (in refrigerator mode)
- Number of cold rooms: 1
- Max. distance between evaporator and compressor: 1.8 meters
- A complete and reliable cooling system for those who want reliable cooling with minimal installation work.
Compressor dimensions
- Width: 220mm
- Height: 160mm
- Depth: 220mm
- Weight: 6.5Kg
Evaporator dimensions
- Width: 300mm
- Height: 245mm
- Depth: 110mm
- Weight: 1.5Kg
- Power requirement 35W
The digital display is clear and allows you to check the temperature from outside the refrigerator. The system is designed to create a stylish user interface, better control and lower power consumption. A temperature sensor inside detects the actual air temperature and combines it with the user-selected settings to determine the compressor operation.
Features:
Easy to read temperature
Compressor operating mode selection (ITC, Eco and cooling)
Three battery charge levels
Excellent compatibility with lithium batteries
ITC
Advantages:
Up to 25% energy savings thanks to the use of a more efficient compressor
Up to 40% savings thanks to stored cooling energy
Rapid cooling at high voltage
Soft start that avoids peak currents
Eco mode
Easy battery voltage level setting directly from the display
Easy to retrofit
Specifications:
Operating voltage: 12-24V
Maximum volume: 100 liters
Evaporator: small cold accumulator
Cold storage dimensions: 300 x 210 x 60mm
Compressor dimensions: 280 x 175 x 160mm
Weight: 14kg
Compressor type: Danfoss BD35F
•Danfoss BD35F
•Small refrigerator
The evaporator (= the one that cools) is an O-evaporator. The evaporator is equipped with a 2-meter soft, slightly bent tube with quick connectors to facilitate the connection of the compressor. Uses average/maximum power at 12 volts, +6°C in the refrigerator compartment and an ambient temperature of +22°C measured in a normally insulated cooler box, half the recommended maximum capacity as above. Average consumption is measured over the entire operating time and maximum consumption with the compressor running.
- Max box volume: 125 liters
- Vaporizer: Small-O
- Operating voltage: 12-24V
- Vaporizer dimensions: 240x210x85mm
- Compressor dimensions: 280x160x160mm
- Weight: 9Kg
- Power consumption Average/Max: 0.6/2.7A
The evaporator (= cooling) is a flat design, which means it can be bent to fit into an existing box. The evaporator is equipped with a 2-meter soft, slightly bent tube with quick connectors to make it easier to connect the compressor.
Means average/maximum power at 12 volts, +6°C in the refrigerator compartment and ambient temperature +22°C measured in a normally insulated cooler box, half the recommended maximum capacity as above. Average consumption is measured over the entire operating time and maximum consumption with the compressor running.
- Operating voltage: 12-24V
- Max box volume: 80 liters
- Evaporator: Flat
- Evaporator dimensions: 350x250mm
- Compressor dimensions: 280x160x160mm
- Average current consumption/maximum: 0.6/2.7A*
- Compressor type: Danfoss BD35F
- Temperature range: Down°C - +2
The Dometic ColdMachine CSX 200 is a modern refrigeration unit developed for marine use. Its design focuses on reliability and performance. The integrated design makes installation smooth and takes up little space on the boat. The unit provides stable cooling for cold rooms of up to 200 liters and helps keep food and drinks fresh for longer. The electronic thermostat allows precise temperature control even in changing conditions at sea. Energy-efficient technology and a more environmentally friendly refrigerant make it a smart choice for marine use.
Suitable for cold rooms up to 200 liters
Fan-assisted cooling speeds up cooling and keeps the temperature constant
Electronic thermostat for precise and stable temperature control
Operates on 12/24 V voltage
Modern R1234yf refrigerant with very low environmental impact
- Cooling up to 200 liters
- Compact all-in-one design
- Fan-assisted cooling
