Water Tank Gauges

Water tank meter for S3/S5 sensors, 0 - 190 ohms.

Water tank gauge for S3/S5 sensors, 0-190 . Installation Ø 52 mm, installation depth 62 mm, total Ø 62 mm. Red and yellow lighting as standard. Operating voltage 12/24 V. Black base / black frame.

This instrument is for those who want to increase comfort on the boat and provide information on when the water tank needs to be filled. It is connected to the S3 or S5 sensor, which are available in lengths from 150 mm to 3000 mm.

Specifications:

- Color: White Silverline

- Ring/bezel: Stainless steel

- Model: Analog

- Operating range: 0-190 ohms (EU standard)

- Backlight: Red or Yellow

- Operating temperature: -25 - +70°C

- Waterproof: IP 67

- Resistant to ozone, UV radiation and salt water: Yes

- Corrosion resistant: Yes

- Power supply: 12/24 V

- Current consumption: 0-130 mA

- Mounting hole diameter: 52 mm

- External dimensions: 56 mm

- Depth: 60 mm

Water tank gauge for S3/S5 sensors, 0-190 ohm. Standard red and yellow lighting. Operating voltage 12/24 V. Black base, stainless steel frame.

Gobius C NMEA 2000 system that measures tank volume continuously from 0 to 100%, version 3.0. Plug and play installation. No need to dismantle the tank. Measurement is done from the top, and there is never a risk of leaks. Complete system, includes everything; sensor, NMEA 2000 cable, 3M cleaning cloth. Voltage: 12 volts. The sensor is installed in the same easy way as other Gobius meters, but from the top. The maximum tank depth is 2 meters and it connects directly to the NMEA 2000 network. Installation is done via your phone using Bluetooth. The app is available in English, but will be available in multiple languages ??in 2024. Measures all types of liquids, including gasoline and diesel.

General information:
- Suitable for all types of containers and liquids
- Plug and play installation
- All settings are done automatically via your phone
- Built-in tank calculator for accurate level measurement
- Built-in compensation for sea movement
- No need to disassemble the tank
- Measures plastic, glass and fiberglass containers
- No limitation on tank wall thickness
- Adapter for metal tanks is available, for standard opening (1.25 inch SAE 5)
- No need to clean the inside of the tank
- No need for maintenance
- Measure silently

Measurement features:
- Measuring range: 20–2000 mm
- Tank depth: Up to 2 meters (78 inches)
- Tank depth: Minimum 0.2 meters (7.8 inches)
- Measurement interval: 1 second
- Resolution: 1mm
- Accuracy: +/- 2-3mm

Container shapes:
- Rectangle
- Indirect railing
- Vertical cylinder
- Horizontal cylinder

Specifications:
- Input power: 9–12 V DC
- Cable connection
- Two digital outputs (level alarm displayed on your phone)
- LED light indicates active/measurement status
- Current consumption: 10 mA
- Built-in Bluetooth, version 5.0
- Built-in temperature sensor
- Built-in accelerometer
- Built-in microwave sensor
- Maximum current: 30 V
- Maximum voltage: 500 mA
- Enable/disable Bluetooth
- Sensor information
- Weight: 65 grams
- Dimensions: height 65 mm, width 95 mm
- Cable length: 1 m
- Cable connection on the sensor
- Sensor material: ABS
- Color: Black
- Waterproof (IP66)

Software:
- App for iOS and Android phones
- Installation/modification/removal/restore
- Correct level measurement, both in % and liters
- Bluetooth, version 5.0
- Enable/disable Bluetooth
- Two digital alarm modes,

SAE 5 adapter made of PETG plastic for mounting the Simarine STR level sensor in a metal tank. The adapter is intended for applications where the radar signal cannot penetrate the tank material. The STR1 or STR2 sensor can be securely mounted on the tank using the SAE 5 hole pitch, allowing accurate liquid level measurement even in metal tanks.

The adapter provides a reliable path for the radar signal and acts as a sturdy, leak-proof mounting base. The durable construction is suitable for boats, motorhomes, campers and other applications with metal fuel, water or waste water tanks.
The package includes the STR-A adapter, gasket, mounting screws and installation instructions. During installation, the tank surface is cleaned, the gasket is placed in place, the adapter is aligned and secured, after which the STR1 or STR2 sensor is mounted on top of the adapter.
