Fixed-Mount Marine VHF Radios
VHF phones for fixed installation from Standard Horizon, Raymarine, Simrad, Lowrance and B&G brands.Fixed-Mount Marine VHF Radios -ryhmän tuotteet
Fixed VHF radio
The Icom IC-M423G is a waterproof VHF radio for fixed installation with a built-in GPS receiver that provides precise location when using DSC distress calls. The radio also features a redesigned white and backlit LCD display that provides clear and legible information.
Main features
- Built-in GPS
- Active noise cancellation
- DSC Class D
- IP67 waterproof design (1 meter depth for 30 minutes)
- Dual/Triwatch feature for monitoring channels 16 and/or alarm channel
- Priority and normal search
- AquaQuake™ speaker dewatering
- 10W speaker
- NMEA connection
- L1 and L2 channels
COMMANDMIC™ (HM-195B/SW) optional
The COMMANDMIC™ accessory, HM-195B/SW, allows the IC-M423G to be operated from another cabin or flybridge. All functions of the IC-M423G can be controlled via the COMMANDMIC™, which can also be used as an intercom for the IC-M423G.
- Built-in GPS
- Active noise cancellation
- DSC Class-D
- No AIS feature
The smallest and highest quality VHF radio on the market
- Dimensions 156.5 × 66.5 × 110.1 mm
- Waterproof construction, IPx7 (does not apply to cables)
- Output power 25/1 W
- 12V supply voltage, negative ground
- Current consumption max. 1A when listening, 5A when transmitting
- Operating temperature -20°C - +60°C
- NMEA 0183 interface for GPS receiver (RMS, GGA, GNS, GLL, DSC, DSE)
- Built-in GPS
- Weight 730g
Garmin VHF 215i AIS marine radio
Features
- Displays AIS (Automatic Identification System) targets on the chartplotter
- Class D DSC (Digital Selective Calling) function (distress calls and direct calls using user-programmed MMSI number)
- In emergency situations, DSC may improve the chances of a quick rescue
- 25 watts of transmit power and internal GPS
- Pre-programmed international boating channels
In the package:
- VHF 215i AIS marine radio
- Detachable handheld microphone
- Handheld microphone mounting stand and accessories
- Rack, knobs and mounting hardware
- Protective cover
- Frame
- Flush mounting gasket
- Power cord
- Guides
- Device dimensions (H x W x D): 9.8 x 19.7 x 14.9 cm
- Weight: radio without microphone 1.2 kg, microphone 0.25 kg
- Water rating: IPX7
- Temperatures: operating -15–70°C, storage -20–70°C
- Compass safety distance: 75 cm
- NMEA 2000: yes
- NMEA 0183: yes
- DSC (Digital Selective Calling): class D
- Frequency bands: all international maritime channels
- Operating voltage: 12.0 Vdc
- Power consumption: standby 350 mA, receiving 600 mA, transmitting 2.0-6.0 A (1-25 W)
- Frequency range: 156.050 MHz–163.275 MHz (including WX channels)
- Megaphone output power: 20 W / 4 ?
- Megaphone impedance: 4 ?
- External speaker impedance: 4?
- Antenna connection: S0-239 (50 ?)
- Maximum antenna gain: 9 dBi
Ray53 DSC VHF radiotelephone
Compact VHF marine radio with Digital Selective Calling
- Built-in GPS/GNSS receiver with connection point for optional external antenna
- NMEA2000 and NMEA0183 networking capabilities allow connectivity to ship systems
- Audio output connector for optional passive remote speaker (A80542)
- Includes wall and hanging bracket mounting kits
- Designed to fit the Axiom chartplotter display family
- Operating voltage: 12V DC
- Operating voltage range: 9V DC - 16V DC
- Power consumption: less than 6 A at high power (13.6 V), standby: 600 mA, reception: 2 A
- Channels: All available US, International and Canadian VHF marine bands
- Frequency range: 156.000–157.425 MHz / 155.500–161.425 MHz (private channels)
- Transmit power: Low transmit power — 1 W, High transmit power — 25 W
- Antenna impedance: 50 ohms
- GPS channels: 72
- Internal GPS antenna
- External GPS antenna: passive via TNC connector
- Cold start: <2min
- Signal update: automatic
- Calendar update: automatic
Premium VHF with built-in AIS receiver and hailer
- Marine VHF with Digital Selective Calling system
- Internal AIS receiver displays target data from chartplotter, radar and gauges
- Fog signal and announcement functions with optional hailer horn (M95435)
- Wired or wireless expansion with optional RayMic handsets
- Internal GPS/GNSS receiver with connection point for optional external antenna
- NMEA2000 and NMEA0183 networking capabilities allow connectivity to ship systems
- Audio output connector for optional passive remote speaker (A80542)
- Includes wall and hanging bracket mounting kits
- Designed to fit the Axiom chartplotter display family
Integroidut AIS- ja GPS-vastaanottimet
Kaksikanavainen AIS-vastaanotin tarkkailee lähellä olevien AIS-alusten sijaintia ja auttaa näin välttämään törmäykset ruuhkaisissa satamissa ja erittäin liikennöidyillä vesiväylillä. AIS-tietoja voi tarkastella RS40-radion näytöstä, kartan päällä tai tutkanäytössä monitoiminäytön kautta. Integroitu GPS-vastaanotin varmistaa, että veneesi sijainti voidaan lähettää DSC-hätäkutsun kanssa, vaikka veneesi muut sähkölaitteet olisivat sammuneet.
Irrotettava käsimikrofoni
RS40-radion irrotettava käsimikrofoni voidaan kytkeä radion etu- tai takaosaan. Lisävarusteena saatavan jatkojohdon kanssa radio ja mikrofoni voidaan asentaa erikseen. Näin voidaan muodostaa helppo ja kustannustehokas ratkaisu asennettavaksi mihin tahansa sijaintiin ilman kaapeliryppäitä. RS40 voidaan esimerkiksi asentaa kattoon ilman riippuvia kaapeleita, kun taas mikrofoni voidaan kytkeä alla olevan kojelaudan lisäpistorasiaan.
Laajennettavissa langattomilla luurisarjoilla
Liittämällä järjestelmään lisävarusteena saatavan luurisarjan voit käyttää radiota kaikkialla veneessä. HS40-luurisarja on suunniteltu RS40-radion intuitiiviseksi ja kannettavaksi yhdyslaitteeksi. Kukin luurisarja näyttää radion näytön ja säätimet, joten voit käyttää kaikkia tärkeimpiä toimintoja etäältä. Yhteen tukiasemaan voidaan liittää jopa kaksi langatonta luurisarjaa. RS40 toimii kätevänä sisäpuhelinjärjestelmänä, kun siihen on kytketty useita luurisarjoja.
SVEA-RAHOITUS
Rahoita isommat ostoksesi SVEA-kulutusluotolla. Luoton voit hakea jo etukäteen, kun tiedät mitä olet ostamassa. Rahoituksella ostaminen ei vaadi myymälään paikan päälle saapumista. Kaupoista voit sopia myös etänä myyjiemme kanssa, kun olet saanut luoton SVEA-hakemuksen kautta.
- D-luokan DSC-hyväksytty VHF-radio
- Kaksikanavainen AIS-vastaanotin
- Integroitu GPS-vastaanotin
- Irrotettava käsimikrofoni tukee etu- ja takaliitäntää
- Kytke jopa kaksi langatonta luurisarjaa
- Liitä lisävarusteena saatava haileri tai ulkoinen kaiutin
- NMEA 0183®. ja NMEA 2000® -liitäntä
GX1400E DSC VHF radiotelephone
ITU-R M493-13 Class D Digital Selective Calling
Warranty: 3 years
- External dimensions: width 131mm, height 50mm, depth 12mm
- Compact Class D fixed VHF
- Built-in 66-channel WAAS GPS receiver
- Meets ITU-R M493-13 Class D DSC requirements
- Built-in separate channel 70 receiver (receiving DSC calls)
- GPS location and time displayed on screen
- Waterproof: IPX8 (submersible to 1.5m for 30min)
- Compact Class D fixed VHF
- New model. Replaces older Eclipse+ and Eclipse DSC models
- Device control buttons also on the microphone
- E2O easy-to-use operating system
- Display size: 31 x 55 mm
- DSC test call and automatic DSC channel change
- NMEA0183 input and output (networking possible)
- Programmable keys
- Automatic GPS position polling for up to six vessels via DSC
- All international, US and Canadian, L and F 1-3 channels
- NOAA weather channels with weather warnings
- Programmable inspection, primary inspection and multi-listening (Dualwatch, three channels simultaneously)
RAM-4 additional handset
High-quality additional handset for fixed-mount Standard Horizon VHF radios. You can control all radio and DSC functions directly from the additional handset and the additional handset has a built-in Strobe light for emergencies. Possibility to program three hotkeys according to your preferences. The device is IPX8, completely waterproof, and comes standard with a 7m connection cable. CT-100 7m extension cable is also available as an accessory. Warranty 3 years.
In the package
- RAM-4 additional handset
- Additional handset holder
- 7m connection cable
- Additional handset for RAM-4 VHF radio
- Waterproof: IPX8
- Remotely control all radio functions and DSC functions
- Two additional RAM-4 handsets can be connected
- Intercom function enables internal communication between the radio and the RAM-4 additional handset
- Channel change and volume control buttons
- Bright LCD display
- Three programmable hotkeys
- Supplied with 7m connection cable
- Optional 21m connection cable
- Strobe emergency light built-in
- Warranty: 3 years
- GPS Antenna
Travel safer on the water with a VHF marine radio
Class B AIS transceiver with built-in GPS. The integrated Class B AIS transceiver lets you see nearby AIS vessels and they can see yours. You can add up to two optional handsets to the system, allowing you to communicate from anywhere on the ship. Plus, the GPS-500 enhances GPS performance.
See and be seen with integrated AIS
The RS40-B includes a Class B AIS transceiver that both receives AIS targets and communicates your vessel’s position to nearby AIS vessels. This allows other mariners to spot your vessel regardless of the conditions, day or night. The built-in AIS receiver monitors the position of nearby AIS vessels, helping to avoid collisions in busy ports and heavily trafficked waterways. AIS data can be viewed on the radio display, on the chart or on the radar screen via the multifunction display.Detachable handheld microphone
The RS40-B radio's detachable handheld microphone can be connected to the front or rear of the radio. With the optional extension cable, the microphone and radio can be mounted separately. This creates an easy and cost-effective solution for installation in any location without the hassle of cables. For example, the RS40-B can be mounted on the ceiling without hanging cables, while the microphone can be connected to an additional socket in the dashboard below.Expandable with wireless handset sets
By connecting the optional HS40 handset to the system, you can use the radio anywhere on your boat. Each handset displays the radio’s display and controls, allowing you to access all key functions remotely. Up to two handsets can be connected to a single RS40-B radio. The radio also functions as an intercom for your vessel when multiple handsets are connected.Note: Radio requires a VHF antenna (sold separately). AIS requires either a second VHF antenna or a VHF/AIS antenna splitter. All DSC functions require an MMSI number issued by your local authority; fees may apply.
Product package contents
- RS40-B VHF radio
- Handheld microphone and holder
- Mounting bracket
- Dashboard set
- Screen protector
- GPS-500 GPS antenna
- Main features:
- Integrated Class B AIS transceiver
- Class D DSC-approved VHF radio
- Integrated GPS receiver
- Detachable handheld microphone supports front and rear connection
- Connect up to two wireless handsets
- Connect an optional hailer or external speaker
- NMEA0183 and NMEA2000 connection
- Includes performance-enhancing GPS-500 GPS antenna
- Class D DSC approved VHF radio
- Dual channel AIS receiver
- Internal GPS antenna
- Two wireless handpieces can be connected
- Can connect an external hailer and external speaker
- NMEA 0183® and NMEA 2000®
You can operate the B&G 60 VHF radio with a remote control and enjoy the benefits of a fixed system with the convenience of a portable device. Conveniently portable, easy to use and wireless handset set gives you complete freedom of movement on your boat.
Wireless control of a fixed VHF radio
The H60 handset allows you to operate your B&G VHF radio remotely. You can make calls, change channels and access DSC emergency functions quickly from anywhere on your boat. The H60 brings full transmit power and all the functionality of a fixed-mount VHF radio to a convenient, portable form factor.
Communication everywhere on the boat
The H60 has a range of up to 100 meters, which is sufficient for the needs of even the largest speedboats. One or more H60 handsets and a V60 base station can also be used as an intercom system to facilitate communication between the ship's crew.
Designed for real-world conditions
The H60 handset is waterproof to IPX7 standard and uses an induction charging system for added protection, as it does not expose the power connectors. The operating time on a full charge is up to approximately 8 hours, allowing you to move freely around your boat.
- Wireless handset kit for V60 or V60-B VHF radio
- The handsets and V60 work together as an intercom system
- Induction charging with included connector
- Battery life up to 8 hours
- 100 meter range from base station
- Fully waterproof (IPX7)
VHF Radio, B-AIS
Navigate the water more safely with this VHF marine radio. Class B AIS transceiver and built-in GPS. The integrated Class B AIS transceiver lets you see nearby AIS vessels and they can see yours. You can add up to two optional handsets to the system, allowing you to communicate from anywhere on the boat.
See and be seen with integrated AIS
The V60-B includes a Class B AIS transceiver that both receives AIS targets and communicates your vessel’s position to nearby AIS vessels. This allows other mariners to spot your vessel regardless of conditions, day or night. The built-in AIS receiver monitors the position of nearby AIS vessels, helping to avoid collisions in busy ports and heavily trafficked waterways. AIS data can be viewed on the radio display, on the chart or on the radar screen via the multifunction display.
Detachable handheld microphone
The V60-B radio's detachable handheld microphone can be connected to the front or rear of the radio. With the optional extension cable, the microphone and radio can be mounted separately. This creates an easy and cost-effective solution for installation in any location without the hassle of cables. For example, the RS40-B can be mounted on the ceiling without hanging cables, while the microphone can be connected to an additional socket in the dashboard below.
Expandable with wireless handset sets
By connecting the optional HS40 handset to the system, you can use the radio anywhere on your boat. Each handset displays the radio’s display and controls, allowing you to access all key functions remotely. Up to two handsets can be connected to a single V60-B radio. The radio also functions as an intercom for your vessel when multiple handsets are connected.
Note: Radio requires a VHF antenna (sold separately). AIS requires either a second VHF antenna or a VHF/AIS antenna splitter. All DSC functions require an MMSI number issued by your local authority; fees may apply.
- Includes Class B AIS transceiver
- Detachable handheld microphone
- Built-in GPS
Wireless control of a fixed VHF radio
The HS40 handset kit allows you to operate your RS40 VHF radio remotely. You can make calls, change channels and access DSC emergency functions quickly from anywhere on your boat. The HS40 brings full transmit power and all the functionality of a fixed-mounted VHF radio to a convenient, portable form factor.
Communication everywhere on the boat
The HS40 has a range of up to 100 meters, which is sufficient for the needs of even the largest speedboats. One or more HS40 handsets and an RS40 base station can also be used as an intercom system to facilitate communication between the ship's crew.
Designed for real-world conditions
The HS40 handset is waterproof to IPX7 standard and uses an induction charging system for added protection, as it does not expose the power connectors. The operating time on a full charge is up to approximately 8 hours, allowing you to move freely around your boat.
- Wireless handset kit for RS40 or RS40-B VHF radio
- The handsets and RS40 work together as an intercom system
- Induction charging with included connector
- Battery life up to 8 hours
- 100 meter range from base station
- Fully waterproof (IPX7)
GPS Marine VHF radio telephone
- Fixed-mount marine VHF radiotelephone with GPS receiver.
- Color black
Lowrance VHF radiotelephone
The Lowrance Link-6 communicates clearly and reliably with a Class D DSC-certified VHF marine radio featuring a four-button handheld microphone, intuitive rotary and push-button controls, and a front-mount design for easy installation.
Highly visible display
Clear visibility in bright daylight on a high-contrast display with black on white. Nighttime visibility has also been taken into account, with the display featuring inverted colors in night mode (white on black), reducing light radiation and improving nighttime visibility.
Intuitive controls
The channel selector allows you to select a channel quickly, while large, widely spaced buttons allow you to quickly access all the main functions. The channel 16 buttons allow you to quickly access the emergency channel. The buttons are located both on the front panel of the radio and on the four-button handheld microphone.
Class D DSC approval
Class D DSC compatibility enables automatic distress calls including location when the system is connected to a compatible GPS receiver.
Three-channel monitoring
You can switch between the current channel, emergency channel 16, and other user-defined priority channels (non-US models). For US models, you can switch between the current channel and emergency channels 16 and 9.
All international channels
Link-6S is designed for global use and supports all international channels including US and Canadian channels.
My Channel mode
Select your favorite channels for quick and easy access. A long press on the channel selector opens the My Channel mode, where you can browse your favorite channels using the channel selector.
Multi-channel browsing mode
Browse all available channels or just your favorite channels. In both browsing modes, emergency channels can be set as priority, ensuring that emergency calls and other urgent safety messages are not missed.
Easy rack or flush mounting
The included mounting foot allows the device to be mounted on a table, ceiling or bulkhead. The device can also be flush-mounted thanks to the easy front mounting solution.
Product package contents
- Link-6S walkie-talkie
- My handheld microphone and holder
- Link-6/RS20/V20 mounting bracket
- Power cord
- Highly visible display with inverted colors in night mode
- Intuitive rotary and button controls
- Four-button handheld microphone
- Class D DSC approval
- Integrated GPS receiver
- Separate emergency channel button
- Three-channel monitoring
- All international channels
- Easy rack or flush mounting
- Internal GPS antenna
Specifications
- Operating voltage 12 V
- Power consumption ?1.5 A, Standby ?0.5 A
- NMEA0183 connection
- Operating temperature range -15C to +55C
- Waterproof IPX7
The Link-9 VHF fixed-mount radio provides complete communication and data transfer capabilities reliably anywhere on the water
The radio includes safety-critical features such as built-in GPS, an internal dual-channel AIS receiver with AIS plotting, NMEA 2000®/0183 connectivity, a call/hailer output with listening function, Track Your Buddy™ and a dedicated MOB button.
GPS location in 4 ways
Equipped with an integrated GPS receiver, the Link-9 includes four ways to ensure GPS position in an emergency: an internal antenna, an SMA connector for a GPS-500 antenna, a NMEA 0183 interface for a chartplotter GPS, and a NMEA 2000® interface for a network antenna connection.Built-in AIS
The dual-channel AIS receiver monitors the position of nearby AIS vessels, helping to avoid collisions in congested ports and heavily trafficked waterways. AIS data can be viewed on the Link-9 radio display, on the chart or on the radar screen via the multifunction display.Remote-mountable handheld microphone
The Link-9 radio's detachable handheld microphone can be connected to the front or rear of the radio. With the optional extension cable, the radio and microphone can be mounted separately, creating an easy and cost-effective solution for installation in any location without the hassle of cables.Easier front installation
The Link-9 radio features easily removable top and bottom bezels with mounting holes underneath, allowing the radio to be mounted from the front, similar to Lowrance multifunction displays.Navigation mode
By pressing the NAV button on the Link-9 radio, you can turn the radio into a navigation device that displays speed and course. The Link-9 also includes a Man Overboard (MOB) feature. By holding down the NAV/MOB button, you can set a waypoint at your current location, which will cause the Link-9 to enter MOB mode and display your distance and heading to a person in the water. The MOB waypoint is also transmitted via NMEA 2000 to other parts of your network.Package contents
- Link-9 walkie-talkie
- My handheld microphone and holder
- Recessed mounting kit
- Screen protector
- Mounting bracket
- Power cord
- Class D fixed DSC VHF receiver
- Internal GPS antenna
- Six-button backlit handheld microphone with remote mountability
- Built-in dual-channel AIS receiver and AIS plotting function
- New front-mount mechanical design for easy installation
- Seamless integration into the wider Lowrance system via NMEA 2000 ® and 0183 interfaces
- Large display and intuitive interface
- Transmitting power 25 W / 1 W
- Very large and precise LCD display
- MOB function
- Track Your Buddy feature
- Dual/triple channel monitoring and all search functions
- Public address/hailer output with listening function
- 10 weather channels
- 20 programmable names with MMSI
- Completely waterproof
- New industrial design inspired by Lowrance multifunction displays
Dual station with VHF-GPS receiver
- Marine VHF with Digital Selective Calling system
- Wired or wireless expansion with optional RayMic handsets
- Built-in GPS/GNSS receiver with connection point for optional external antenna
- NMEA2000 and NMEA0183 networking capabilities allow connectivity to ship systems
- Audio output connector for optional passive remote speaker (A80542)
- Includes wall and hanging bracket mounting kits
- Designed to fit Axiom's multifunction display family
- Raymic extension cord
- Length 5m
- Fits Ray63, 73 & 90/91
VHF telephone with transmitting and receiving AIS700
- Black box ensures discreet installation and saves space on the dashboard
- Multi-station and high-performance VHF radio
- Cordless handset and active speaker available
- Includes wired handset and passive speaker
- Expandable to two handsets
- Built-in hailer and fog signal generator
- GPS receiver (optional external antenna)
- Class D Digital Selective Calling system
- Simple NMEA200 and NMEA0183 network
