Special anodes

Zinc anode Side Power 4HP -99

A zinc anode suitable for Side Power bow thrusters that protects the bow thruster and related metal parts from corrosion. The anode acts as a sacrificial shield and prevents electrochemical corrosion in demanding marine and brackish water conditions.

Compatibility

Fits the following Side Power model

• 4HP -99

Specifications

• Material zinc

• Height 20 mm

• Diameter 26 mm

• Mounting hole diameter 6.5 mm or 10 mm

• Weight 40g

Additional information

• Corresponds to original part number 61180

Installation and maintenance

• Installed on the bow thruster according to the manufacturer's instructions

• The zinc anode must not be painted.

• Check the anode regularly, especially when lifting the boat.

• Replace the anode when it is clearly worn.

A regularly replaced Side Power zinc anode extends the life of the bow thruster and ensures reliable operation throughout the boating season.

Zinc anode for Side Power bow thrusters SE30 SE40 SP30 SP30SI

A zinc anode suitable for Side Power bow thrusters, which protects the bow thruster and related metal parts from corrosion. The anode acts as a sacrificial shield and prevents electrochemical corrosion, especially in marine and brackish water use.

Compatibility

Fits the following Side Power models

• SE30

• SE40

• SP30

• SP30SI

Specifications

• Material zinc

• Height 15mm

• Diameter 26 mm

• Mounting hole diameter 5 mm

• Weight 30g

Installation and maintenance

• Installed on the bow thruster according to the manufacturer's instructions

• The zinc anode must not be painted.

• Check the anode regularly

• Replace the anode when it is clearly worn.

A regularly replaced Side Power zinc anode extends the life of the bow thruster and ensures reliable operation throughout the boating season.

Zinc anode Isotherm

Zinc anode suitable for Isotherm devices, which protects the surfaces of the heat exchanger and other underwater metal parts from corrosion. The anode acts as a sacrificial shield and prevents electrochemical corrosion, especially when used in seawater.

Compatibility

• Isotherm equipment

• Corresponds to the original Isotherm spare part

Specifications

• Material zinc

• Weight 0.24 kg

• Outer diameter 101 mm

• Height 10mm

• Inner diameter 42 mm

• Mounting hole diameter 52 mm

• Mounting hole diameter 5 mm

Additional information

• Corresponds to original part number SBE00006AA / 39051

Installation and maintenance

• Installed in the Isotherm device according to the manufacturer's instructions

• The zinc anode must not be painted.

• Check the anode regularly during maintenance

• Replace the anode in time when it is clearly worn out.

A regularly replaced Isotherm zinc anode extends the life of the device and helps prevent damage caused by corrosion.

Zinc anode Side Power SP55S SE60 SE80

A zinc anode suitable for Side Power bow thrusters, which protects the bow thruster and related metal parts from corrosion. The anode acts as a sacrificial shield and prevents electrochemical corrosion, especially in marine and brackish water use.

Compatibility

Fits the following Side Power models

• SE55

• SE55S

• SP55S

• SE60

• SE80

Specifications

• Material zinc

• Height 20 mm

• Width 19mm

• Diameter 45 mm

• Mounting hole diameter 6 mm

• Inner diameter 40 mm

• Weight 120g

Installation and maintenance

• Installed on the bow thruster according to the manufacturer's instructions

• The zinc anode must not be painted.

• Check the anode regularly during boat maintenance.

• Replace the anode in time when it is clearly worn out.

A regularly replaced Side Power zinc anode extends the life of the bow thruster and ensures reliable operation throughout the boating season.

Zinc anode for Flexofold propeller

Round zinc anode for Flexofold and Flex & Fold propellers. The anode protects the propeller and other underwater metal parts from corrosion by acting as a sacrificial shield. The zinc corrodes first, thus preventing damage to more valuable metal parts, especially in marine and brackish water use.

Compatibility

• Flexofold

• Flex & Fold propellers

Product features

• Round zinc anode

• Effective corrosion protection for the propeller

• Even and controlled etching

• Suitable for demanding marine conditions

Specifications

• Material zinc

• Weight 0.54 kg

• Diameter 69.5 mm

• Thickness 37 mm

• Mounting hole diameter 11 mm

• Mounting hole spacing 59.4 mm

Installation and maintenance

• Installed on the propeller according to the manufacturer's instructions

• The zinc anode must not be painted.

• Check the anode regularly, especially when lifting the boat.

• Replace the anode in time when it is clearly worn out.

A regularly replaced Flexofold zinc anode extends the life of the propeller and ensures reliable operation throughout the boating season.

OMC anode Evinrude Johnson 2-150 hp

Zinc anode suitable for Evinrude and Johnson OMC outboard motors. The anode is designed to protect the metal parts of the engine from corrosion and extend their service life, especially in seawater and other demanding operating conditions.

The zinc anode acts as a sacrificial shield and prevents electrochemical corrosion that occurs when different metals are in contact with each other underwater.

Compatibility

Fits Evinrude and Johnson OMC outboards

• Power class 2–150 hp

Specifications

• Material zinc

• Diameter 61 mm

• Width 25 mm

Maintenance and use

• The anode should be checked regularly, especially when the boat is lifted.

• Replace the anode when it is clearly worn.

• A worn anode no longer provides sufficient corrosion protection

A regularly replaced zinc anode helps keep the metal parts of your Evinrude and Johnson engine in good condition and prevents damage from corrosion.

Zinc anode for protecting metal parts of a boat

A zinc anode protects iron and other metal parts of a boat from corrosion. The anode is installed below the waterline on the areas that need to be protected, and it acts as a sacrificial shield against corrosion.

Corrosion occurs electrochemically when different metals are in contact with each other under water. In this case, the metals act like an electric battery, with water connecting the terminals. In this combination, the baser metal always corrodes first. Zinc is a baser metal compared to, for example, iron, stainless steel, copper and brass, which makes it effective in protecting more valuable metal parts.

Operation and installation

• The anode is always installed below the waterline.

• Installed longitudinally in connection with the metal parts to be protected

• The shaft anode is attached to the propeller shaft as close as possible to the shaft support.

• The zinc anode must not be painted with boat primer.

Maintenance and inspection

• Zinc anodes should be checked every time the boat is lifted.

• The anode must be replaced immediately if it is clearly worn.

• A worn anode no longer provides sufficient protection for metal parts

A regularly inspected and timely replaced zinc anode extends the life of the boat's metal parts and helps prevent damage due to corrosion.

Zinc anode Sleipner XF60/BP600/SR60

This zinc anode is designed to protect Sleipner towing equipment from corrosion. It fits the XF60, SR, VR, BP600 and SR60 models.

A zinc anode extends the life of the equipment when installed correctly and inspected regularly.

Compatibility:

• XF60

• SR

• VR

• BP600

• SR60

Additional zinc anode for Radice axle nut

Radice shaft anode supplement zinc, intended for use with Radice nut-type shaft anodes. The supplemental anode increases the anode mass and improves corrosion protection of the propeller shaft and associated metal parts, especially in demanding conditions.

Compatibility

• Radice axle nut anodes

• Axle nuts, size 22–25 mm

Product features

• Additional anode for Radice nut anode

• Increase anode mass and service life

• Improves corrosion protection on the propeller shaft

Operation and maintenance

• Installed in connection with the Radice axle nut anode

• No painting allowed

• Check the auxiliary anode regularly

• Replace the anode when it is clearly worn.

An additional zinc anode is an easy way to enhance propeller shaft protection and extend the life of both the shaft and the anode during the boating season.

Zinc anode for Radice axle nut 30mm

Zinc anode for Radice shafts, installed in connection with the shaft nut. The anode protects the propeller shaft and other underwater metal parts from corrosion by acting as a sacrificial shield. Especially suitable for shaft-driven boats in seawater and brackish water use.

The zinc anode prevents electrochemical corrosion and helps extend the life of the propeller shaft and related metal parts.

Compatibility

• Radice axle nut

• Axle nut size 30 mm

Features

• Designed to be mounted on the axle nut

• Effective corrosion protection for propeller shafts

• Easy installation and replacement

• Suitable for demanding marine conditions

Installation and maintenance

• Installed in connection with the axle nut below the waterline

• The zinc anode must not be painted.

• Check the anode every time you lift the boat.

• Replace the anode in time when it is clearly worn out.

A regularly checked and replaced Radice zinc anode ensures reliable corrosion protection of the propeller shaft and reduces the risk of damage caused by corrosion.

Zinc anode for Radice axle nut 40 mm

A zinc anode for the Radice shaft nut that protects the propeller shaft and related metal parts from corrosion. The anode acts as a sacrificial metal and prevents electrochemical corrosion, especially in demanding marine conditions.

Compatibility

• Radice axle nuts

• Axle nut size 40 mm

Features

• Mounts directly on the axle nut

• Effective corrosion protection for propeller shafts

• Easy to install and replace

• Suitable for seawater and brackish water use

Installation and maintenance

• Installed below the waterline in connection with the axle nut

• The zinc anode must not be painted.

• Check the anode every time you lift the boat.

• Replace the anode in time when it is clearly worn out.

A regularly replaced Radice zinc anode extends the life of the propeller shaft and helps prevent corrosion damage to the boat's drivetrain.

Shaft anode nut model Radice

Radice zinc anode for propeller shafts in a nut shape. The anode protects the propeller shaft and other underwater metal parts from corrosion by acting as a sacrificial shield. Especially suitable for shaft-driven boats where an easy and reliable anode solution is desired.

The zinc anode prevents electrochemical corrosion and extends the service life of the shaft and related metal parts in demanding marine conditions.

Compatibility

• Propeller shafts, diameter 20–25 mm

• Nut-shaped shaft anode

Specifications

• Material zinc

• Weight 120g

• Outer diameter 34 mm

• Inner diameter 7 mm

• Inner diameter 2 11 mm

• Shaft diameter 20–25 mm

• Hexagon head 22 mm

• Height 39 mm

Operation and maintenance

• Mounted on the propeller shaft below the waterline

• Do not paint with primer.

• Check the anode every time you lift the boat.

• Replace the anode in time when it is clearly worn out.

A regularly inspected and replaced Radice shaft anode ensures effective corrosion protection and reliable operation of the propeller shaft throughout the boating season.

Shaft anode nut model Radice

Radice zinc anode for propeller shaft, nut model. The anode is intended to protect the propeller shaft and other underwater metal parts from corrosion by acting as a sacrificial shield.

The zinc anode prevents electrochemical corrosion and extends the life of the shaft and related metal parts, especially in seawater applications. The nut-like design ensures a sturdy and easy installation.

Compatibility

• Propeller shafts, diameter 35 mm

• Shaft-driven boats

Specifications

• Material zinc

• Weight 360g

• Outer diameter 46 mm

• Inner diameter 9 mm

• Inner diameter 2 18 mm

• Shaft diameter 35 mm

• Hexagon head 32 mm

• Height 62 mm

Installation and maintenance

• Mounted on the propeller shaft below the waterline

• The zinc anode must not be painted.

• Check the anode every time you lift the boat.

• Replace the anode in time when it is clearly worn out.

A regularly inspected and replaced Radice shaft anode ensures effective corrosion protection and reliable operation throughout the boating season.

Shaft anode nut model Radice

Radice zinc anode for propeller shaft, nut model. The anode is designed to protect the propeller shaft and other underwater metal parts from corrosion by acting as a sacrificial shield, especially in seawater use.

Zinc is a more base metal than the shaft and propeller materials, which means it corrodes first, protecting the more valuable parts. The nut-like design allows for a sturdy and easy installation on the shaft.

Compatibility

• Propeller shafts, diameter 40 mm

• Shaft-driven boats

Specifications

• Material zinc

• Weight 460g

• Outer diameter 52 mm

• Inner diameter 9 mm

• Inner diameter 2 18 mm

• Shaft diameter 40 mm

• Hexagon head 36 mm

• Height 67mm

Installation and maintenance

• Mounted on the propeller shaft below the waterline

• The zinc anode must not be painted.

• Check the anode every time you lift the boat.

• Replace the anode when it is clearly worn.

A regularly inspected and timely replaced Radice shaft anode extends the life of the propeller shaft and other metal parts and helps prevent corrosion damage.

Zinc anode for Radice axle nut 30 mm

A zinc anode for the Radice shaft nut that protects the propeller shaft and related metal parts from corrosion. The anode acts as a sacrificial metal and prevents electrochemical corrosion, especially in seawater applications.

Compatibility

• Radice axle nuts

• Axle nut size 30 mm

Features

• Mounts directly on the axle nut

• Effective corrosion protection for propeller shafts

• Easy to install and replace

• Suitable for seawater and brackish water use

Installation and maintenance

• Installed below the waterline in connection with the axle nut

• The zinc anode must not be painted.

• Check the anode every time you lift the boat.

• Replace the anode immediately when it is clearly worn.

A regularly replaced Radice zinc anode extends the life of the propeller shaft and helps prevent corrosion damage to the boat's drivetrain.

Shaft anode, two-piece, for 25 mm shaft

Two-piece short zinc anode for propeller shafts. The anode consists of two halves that are tightened together with screws. A set of screws and nuts is included in the delivery. Especially suitable for situations where there is limited space for the anode on the shaft.

The zinc anode protects the propeller shaft and other underwater metal parts from corrosion by acting as a sacrificial metal.

Compatibility

• Propeller shafts, diameter 25 mm

• Shaft-driven boats

Specifications

• Material zinc

• Inner diameter 25 mm

• Outer diameter 55 mm

• Height 25 mm

• Two-piece structure

• Fastening with screws and nuts

Installation and maintenance

• Mounted on the propeller shaft below the waterline

• The halves are tightened evenly around the shaft

• The zinc anode must not be painted.

• Check the anode every time you lift the boat.

• Replace the anode when it is clearly worn.

The two-piece shaft anode is easy to install without removing the shaft and provides effective corrosion protection for the propeller shaft during the boating season.

Zinc anode for Martec heat exchangers

Zinc anode for Martec heat exchangers, which protects the internal metal surfaces of the heat exchanger from corrosion. The anode acts as a sacrificial shield and prevents electrochemical corrosion in the engine cooling system.

Regular inspection and replacement of anodes is important to ensure the service life of the heat exchanger and proper cooling operation.

Compatibility

• Martec 2 inch heat exchangers

Specifications

• Material zinc

• Thread 1/4 inch taper thread

• Anode length 15 mm

Operation and maintenance

• Installed in the anode position of the heat exchanger

• Check the anode regularly during maintenance

• Replace the anode when it is clearly worn.

• A worn anode no longer protects the heat exchanger effectively.

A regularly replaced Martec zinc anode helps prevent corrosion damage and extends the life of the heat exchanger in demanding marine conditions.
