Wind sensors and indicators
High-quality wind gauges and indicators for boats.Wind sensors and indicators -ryhmän tuotteet
The Windex® 6 wind direction indicator is the latest addition to the Windex® family. It is the perfect wind indicator for smaller boats/yachts or other fast sailing vessels.
Suitable for masts or bows with a diameter of 45-70 mm. You can choose from several different ways to attach the Windex® 6 to Optimist, Laser or multihulls.
- Arrow length 150 mm
- Total length/height depending on installation method: 300 mm
- Weight 17g
- Includes rubber band that fits 45-70 mm pipes
- Mast mount available for purchase separately
Windex 10C is a smaller version of the popular Windex 15' model. Windex 10C is suitable for both cruising and racing boats and is recommended for use on 10-20 foot boats.
The Windex Wind Indicator offers exceptional performance, capable of measuring wind changes of as little as one degree. The secret is a needle resting on a sapphire layer, meaning the Windex 15 can detect changes even in very light winds.
Reflective tape on the blade and grip strips ensure that the pointer is easily visible day and night. Windex® blades are durable and, when properly installed, will provide many years of use. They have been wind tunnel tested to 40 m/s wind speeds.
The Windex 10 C model can also be equipped with a light, which is sold separately.
- Arrow length 250 mm
- Height: 270mm
- Weight: 31g
- Recommended for 10-20 foot boats
- Maximum mast height 8-9m for best performance
- Mounting thread: 5/16” or mount by drilling an 8mm hole and using a washer and nut
The Windex® 15 BirdSpike attachment is the perfect choice for all sailboats and racing boats 5-12 meters (15-40 feet) in length that have problems with birds on the mast. If you don't want to use the birdspike, it can easily be unscrewed.
The WINDEX wind detector offers exceptional performance. The secret lies in the needle, which detects wind direction even in very light winds. The included carbon fiber BirdSpike keeps birds away from the Windex without affecting its operation.
- The most popular wind direction indicator.
- For 15-40 foot boats.
- With the Birdspike add-on.
- Wind sensor length: 380 mm
- Height: 520 mm (with bird spike), 330 mm (without)
- Weight: 102g
- Bird-proof spike, height 190 mm.
- Reflective tape on the pointer and body.
- Tested in a wind tunnel at wind speeds of up to 40 m/s.
- Accurate apparent wind direction information for both cruising sailors and racing sailors.
- The spring mount with a sapphire jewel makes the device more sensitive in light winds and faster to respond in strong winds.
- Windex® indicators are the world's best wind indicators, offering exceptional performance at an excellent price.
When you use both the GNX Wind device and the gWind 2 wireless wind sensor, you have accurate wind data at your fingertips. The package includes the Garmin gWind 2 wireless wind sensor, GNX Wind display, mast mount, and mounting hardware.
- Includes GNX™ Wind device and gWind™ 2 wireless wind sensor
- When used with a compatible GPS chartplotter, the GNX Wind's two data fields and digital wind rose simultaneously display information such as true and apparent wind, autopilot, and boat speed.
- Displays true and apparent wind speed and angle, true wind direction, boat speed, speed over ground, speed advantage, heading, heading over ground, and heel angle
- Includes easy-to-install gWind 2 wireless wind sensor, eliminating the need to run cables through the mast up to 15 meters (50 feet)
- The internal solar-charged battery lasts for 3 years and is easy to replace
The mainsail's maintails should be installed at even intervals along the trailing edge of the sail to ensure accurate trimming of the mainsail when sailing into a headwind or crosswind.
- 8 pcs of flux wires
- 8 pcs Dacron mounting plates
- Designed for mainsail
- Color: black-red
8 pairs of flow lines for the headsail.
- 8 pcs green flux threads
- 8 pcs red flux threads
- 16 self-adhesive sheets
- Designed for headsail
Self-tapping. Makes it easier to adjust the sails for best speed and direction. Includes: 16 pieces, 8 red and 8 blue.
Short-wave wind sensor
The wired RSW Smart Wind wind sensor is a professional-grade wind sensor designed to provide highly accurate and calibrated wind speed and direction data. Supplied as standard with a 30m Smart Wind mast cable.
Designed by sailors for sailors, the transducer is lightweight yet extremely strong. The 3D motion sensor takes into account pitch and roll, while Raymarine's Smart Wind technology compensates for mast twist and bend and sail heave.
Install and go
Raymarine Smart Wind technology delivers expert-level accuracy without the need for expensive new processors or extensive calibrations and settings.
Fine-tuned
Through rigorous wind tunnel testing, we have fine-tuned and balanced the meter to ensure that the masthead data is accurate and consistent
Sail smarter
Reliable and highly accurate true wind data, combined with high-performance Alpha displays and Axiom chartplotters, enable smarter sailing.
In the package
- Wind sensor
- Wired Smart Wind Converter
- SeaTalk NG® to DeviceNet adapter cable, 120 mm
- Mast cable, 30 m
- 40 mm heat shrink tubing (needed to insulate the ground wire when shortening the mast cable)
- Ring crimp connector (required for additional ground connection when the converter is not mounted on a metal surface)
- Required screws
- Wired wind sensor
- Short-armed
- Operating voltage: 12V DC
- Operating voltage: 9-16V DC
- Power consumption: < 100mW
- Fuse ratings: Ensure that the SeaTalk NG backbone is protected by a 5A fuse
- Ultra-light, hand-made wind direction indicator. Sensitive indicator that shows wind direction changes of 0.8 knots up to 40 knots.
Designed for small racing boats (yachts up) - Recommended for boats up to 6m
- Wind direction indicator
- Length: 220mm
- Height: 270mm
- Manufacturer: Ronstan
Stainless steel rod and bracket.
RACE 1 mast mount wind vane for racing sailors. Stable: no overreaction, minimal vibration. Carbon fiber construction: withstands stress even in tough competition. Frictionless bearings: Race 1 core. Ultra-light: less than 10 g. Ultra-sensitive: 0.3 mm thick carbon fiber rudder picks up even the lightest wind data.
Spare arrow for Windex 10 wind direction indicator. Easy to attach.
- Just a pointer
- Windex product code: 850-1
Windex 10 wind direction indicator index arm + adjustment flags.
- Spare part
- Compatible with: Windex 10 wind direction indicator
Additional bracket for attaching the weather vane to the mast. Fits Windex 15.
Spare arrow for Windex 15 wind direction indicator. Easy to attach.
- Just a pointer
- Windex product code: 800-1
Windex 15 wind direction indicator index arm + adjustment flags.
- Control flags
- Fits Windex 15 wind direction indicator
Mast mount for Windex 6 wind indicator.
- Mastokiinnike
- Yhteensopiva: Windex 6
Spare arrow for Windex 6 Dinghy wind direction indicator. Easy to attach.
- Just a pointer
- Windex product code: 880-1
Windex XL - for large boats over 40 feet. This wind vane is the perfect aid for reading wind direction day and night. The crosshairs and reflective tape make the Windex XL clearly visible even at night. The model was developed as sailboats have grown over time, and the XL is suitable for boats from 40 to 100 feet (12 to 30 meters).
Windex XL is an easy-to-read wind indicator that offers, among other things:
- Cross-references
- Good visibility day/night
- High performance
- Sapphire bearings
- Excellent price-quality ratio
All this and top quality.
The technology is the same as in the smaller Windex models, such as sapphire bearings. The wind vane has been tested in very strong winds of 40 m/s and its good quality guarantees a long service life when installed correctly.
Suitable for both recreational and racing boats.
Specifications:
Height: 570mm
Weight: 150g
Suitable for boats: 40-100 feet (12-30 meters)
- Wind direction indicator
- For boats over 40 feet
- Length: 570mm
