Ultraflex Hydraulic Steering Kit Max 175hp Outboard Motors

Hydraulic steering package for outboard motors up to 175hp

"Bullhorn" style hydraulic cylinder, meaning the cylinder has the same stroke length SB and BB, allowing for easier installation in narrow engine bays. The steering is very easy to install and will fit most outboard motors as listed below. The system is supplied complete with pump, cylinder, 6m dual hose with fittings and 2 litres of hydraulic oil. The hydraulic steering has a "non-feedback" function, meaning the engine will not move if you let go of the steering wheel. Not suitable for use on boats travelling over 48 knots.

Specifications:

Cylinder:

• Stroke: 186mm
• Piston force: 278kg
• Cylinder volume: 95cm3
• Cylinder body length: 551mm

Pump:

• Volume: 20 cm3 / wheel revolution
• Max pressure: 50bar
• Diameter: 127mm
• Connections: R 3/8"
• Max wheel diameter: 508mm


The package includes:

• 1 steering pump UP 20F with check valve
• 1 cylinder UC 95-OBF
• 2 liters of hydraulic oil
• high-pressure hose
• 2 x 6m + 4 nipples


Fits the following outboard motors:

• Mercury/Mariner:
  50-75-90 2-stroke (years 1990-2008)
  100-115-150 EFI 2-stroke (year 1991-2007)
  75-90-115 Optimax (year 1999-2018)*
  125-135-150-175 Optimax (year 1999-2018)
  40-50-60 EFI 4-stroke (2004 onwards)
  75-80-90 EFI 4-stroke (2000 onwards)
  100-115-150 EFI 4-stroke (2007 onwards)
  175 V6 4-stroke (2018 onwards)

• Evinrude:
  E40-E50-E55-E60 2-stroke (year 2004-2020)
  E75-E90 2-stroke (year 2004-2020)
  E115-E130-E135 V4 2-stroke (year 1995-2020)
  E150-E175 V6 2-stroke (year 1995-2020)

• Yamaha:
  60-70 2-stroke (years 1984-2008)
  75C-90 2-stroke (year 1998-2008)
  115C-130B-150F 2-stroke (year 1990-2008)
  150-175 HPDI VMAX (year 2000-2007)
  F60-F75-F80 EFI 4-stroke (year 1999-2007)
  F90-F100-F115-F150 EFI 4-stroke (year 1999-2007)
  F115-F150-F175 4-cyl. 4-stroke (from 2004 onwards)

• Honda:
  BF75-BF80-BF90-BF100 4-stroke (1995 onwards)
  BF115A 4-stroke (2009 onwards)
  BF115F-BF130A 4-stroke (year 1998-2009)*
  BF135-BF150 4-stroke (2005 onwards)
  BF175 4-stroke (2001 onwards)

• Suzuki:
  DF70-DF80-DF90 4-stroke (1998 onwards)**
  DF100-DF115-DF140 4-stroke (2008 onwards)
  DF150-DF175 4-stroke (2006 onwards)

• Tohatsu/Nissan:
  115-120-140 2-stroke (2004 onwards)*
  70-90-115 TLDI 4-stroke (2004 onwards)
  BFT60-BFT75-BFT90-BFT100 4-stroke (from 2015 onwards)
  BFT115-BFT150 4-stroke (2015 onwards)
  MFS50-MFS60-MFS75-MFS90-MFS100-MFS115 4-stroke (2018 onwards)

• Clear:
  80 Portofino/Tigershark (year 1995-2008)
  150 White Shark (year 2001-2007)
  100 EFI Marlin (year 2001-2007)
  115 EFI Narwhai (year 2001-2007)
  100-150 EFI Killer Whale (2000 onwards)

• Johnson :
  BJ70-BJ90-BJ115-BJ140 4-stroke (year 2001-2007)
  J90-J115 V4 2-stroke (year 1995-2007)
  J150-J175 V6 2-stroke (year 1995-2007)

• Neanderthal Shark
  DTORQUE 111 (from 2020 onwards)

* Requires a second hydraulic cylinder with part number 93053
** Suzuki engines up to 2008 require adapter with part number 93019
